COMPACT ROTARY ACTUATOR WITH BRASS DIVERTER VALVE
Electric motor driven actuator EMV110 with installed 3-way brass valve
operate as diverting or separating element in closed systems of remote
Supply voltage: 230VAC/50Hz
(warm water), air blast or combined heating systems using either of the
Power consumption: 7VA
sources, remote or air blast heating.
Protection class (in accordance with EN-60335-1): II
Enclosure rating (in accordance with IEC60529):
Special construction enables minimum valve leakage and maintenance-
IP40
free operation
In accordance with: EMC directive: 2004/108/EEC,
Design for use in house applications and small industrial applications
LV Directive: 2006/95/EEC, PAH directive: 2005/69/
Actuator is simply and quickly assembled and disassembled from valve by
EEC
means of “clip” system
Ambient temperature: 0…55°C
Simple electrical connection “MOLEX connector”
Humidity: RH 0%...80% (non condensed)
Built-in relay module enables two wire control SPST
Storage temperature: -10…+70°C
Connection cord: molex 3x0.75mm2, L=1m
Position indication: on actuator cover
Possibility of manual control: no
Built in relay module: yes
Opening/closing time: 8s/60°
Connections: 3-port, compression connection
Medium: water
Medium temperature: +5°C…90°C
Working pressure: max. 10bar
Material:
Valve body: brass UNI EN 12165CW617N
Rotor axis: brass UNI EN 12165CW617N
O-rings: TPE, Polypropylene
ROTODIVERT FC
Code
Type
Voltage
C
H
L
Kvs
kg
*10567
EMV 110 526/89I0-3
DN20 - 3/4", FFF (inner thread),
3/4”FFF
128
93
7,5
0,83
230VAC, 50Hz
*10569
EMV 110 526/89I0-4
DN25 - 1", MMM (external thread),
1”MMM
127
93
7,5
0.92
230VAC, 50Hz
*10590
EMV 110 526/89I0-compr 22mm
mm22
138
110
7,5
0,94
*10591
EMV 110 526/89I0-compr 28mm
mm28
144
119
7,5
0,99
* Kvs=m3/h
p=1bar
|
