Products - ACTUATORS For rotary mixers, reversible and ball valves


2-way and 3-way valves

FIRŠT actuators EMV 110, series COMPACT, are 2-point control actuators designed for operating 2-way and 3-way valves with flexible holder system and clip system (DN 15 - DN 32).

  • The FIRŠT COMPACT actuators have not defined (ND) direction of rotation 90°/360°.
  • Actuators are available with cable connection.
  • Recommended for on/off and diverting applications.

Back to products / ACTUATORS


COMPACT, for 2-way and 3-way ball valves (90° rotation)

Code TYPE Voltage Rotation time Control signal Connection Max. torque [Nm] Weight [kg]
20119 4230-K 230 VAC 50 Hz 30s/90° 2-point SPST Cable 8 0,48
20126 4930-K 230 VAC 50 Hz 30s/90° 2-point SPST Cable 8 0,48
20127 4950-K 230 VAC 50 Hz 60s/180° 2-point SPST Cable 8 0,48
Control: 2-point SPST
Supply voltage: 230 VAC 50Hz / 24 VAC 50Hz
Rotation time: 30s/90°, 60s/180°
Power consumption: 9 VA (operation), 5 VA (stand by relay on),
0 VA (stand by relay off)
Max.Torque:   8Nm
Protection class: II
Enclosure rating: IP44
Connection: cable 1,5 m, 4 x 0,5 mm2
Direction of rotation: ND, undefined CW/CCW (90°/360°; 180°/ 360°)
Manual operation: yes (with flexible holder system)
Position indicator: with position indicator
Media temperature: +2°C..+110°C (With optional SCA adaptor -15°C to +125°C, briefly up to +150°C)
Ambient temperature: 0°C..+55°C
Storage temperature: -10°C..+70°C
Humidity: 0%..80% R.H. (non condensed)


COMPACT is an electric actuator designed for operating 2-way and 3-way valves. Actuators are controlled by 2-point SPST signal built-in relay module. FIRŠT COMPACT actuators allow high regulating accuracy and easy installation with one-click CLIP system or flexible holder system.
Actuators are available in 230V AC 50 Hz / 24V AC 50 Hz and are supplied with a 1,5m attached connection cable. Actuator can be manually operated (4230). COMPACT actuators are recommended for on/off applications.
Actuators 4230 with FBV 200C (DN15 - DN32), and actuators 4930 with FBV 600 valves (DN 15- DN 32). Compact actuators can also be used for diverting applications. Actuators 4950 with FBV 230C-L valves. Anti blocking function provides that in case of blockade the motor changes its direction. Because of that feature, the motor is able to save itself from stopping.

Installation position:


Electrical connection:


Installation examples:




Available as zone unit: Compact 200C

Available as zone unit: Compact 600
